Hafele 356.11.470 Adapter for SMOVE, Face-Frame with Lip Salice, D066SNBN Beige
Product Information
Description
Manufacturer: Hafele
Item: 356.11.470
Product Title: Adapter for SMOVE, Face-Frame with Lip, Salice, D066SNBN Beige
Category: Adapter for SMOVE, Face-Frame with Lip, Salice, D066SNBN Beige
Item Details
- Adapters allow surface mounting, making on-site installation easy
- Model : D066SNBN
- Area of application : For face-frame doors with lip
- Installation : 1. Clean and de-grease the cabinet surface where the adapter is to be installed using denatured alcohol or an acetone based cleaner.2. Remove the protective strip from the adhesive.3. Place the adapter in position and apply a firm pressure for about one minute.4. Insert SMOVE into the adapter.5. Allow a period of 12 hours to elapse before usingData Sheet
Specifications
For detailed PDF specifications, click:
Hafele Catalog Page: selection_9.45-9.46.pdfHafele 356.11.470, 356-11-470, 35611470, 356.11
Specifications/Hafele Catalog - Page# FC9.79:
Click to: Show catalog here ...
Click to: Show catalog in a new page.
Return to: Hafele Hinges & Stays Catalog
Return to: All Hafele CatalogsDownload
Adobe PDF Reader
Brand PDF Catalogs
Click on a Category to open a PDF catalog:
Sliding and Folding Catalog
Fineline Brochure
Free Flap Fittings Brochure
The Complete Architectural Hardware Catalog
Dialock In Hotels Catalog
Dialock System Catalog
IXConnect Invisible Heroes
One Room One Face Catalog
Architectural Hardware: American Standard Catalog
Closet Catalog
Decorative Wood Catalog
Cornerstone Catalog
Decorative Hardware Catalog
Kitchen Solutions Catalog
Loox5 Lighting Catalog
Furniture Cabinetry Hardware Catalog
Designing Accessibility HEWI Catalog
The Complete CabinetRequired Products & Optional Accessories
Optional Accessories:- Twist drill bit, Twist
Quick Metric Conversions: 25mm = 1 inch (approx), 2.5cm = 1 inch (approx), 96mm = 3.75 inches
