Hafele 940.94.003 Futura Framing Kit, type 3Zoom

Hafele 940.94.003 Futura Framing Kit, type 3

$476.10$634.80You Save: $158.70 (25%)
Item# Hafele-940-94-003
Availability: Usually ships in 3-4 business days

Product Information

  • Description

    Hafele 940.94.003 Pocket Door Framing Kit, Futura
    Type III



    Application :
    For Junior 40Z and 80Z


    Suitable for :
    Jr. 80

    For door thickness :
    up to 44 mm (1 3/4”)



    Supplied with :
    • 1 x Header assembly
    • 2 x Front vertical stud
    • 2 x Back vertical stud
    • 4 x Floor plates (2 x front and 2 x back)
    • 2 x Filler strip
    • 1 x joing plate
    • Mounting screws



  • Specifications

    For detailed PDF specifications, click:
    Hafele Sliding Door Catalog Page: selection_1.189-1.191.pdf

    Hafele 940.94.003 Futura Framing Kit, type 3
    • Hardware > Hardware Accessories
    • Hardware,Hafele,50-500
    • Brand: Hafele
    • Part#: 940.94.003
    • Condition: new
  • Installation Manuals

Need help finding a product? Call us toll free: 1-877-765-4052 (M-F 9-5 EST)

Quick Metric Conversions: 25mm = 1 inch (approx), 2.5cm = 1 inch (approx), 96mm = 3.75 inches
