Hafele 940.94.002 Pocket Door Framing Kit, Futura Type II

Product Information

• Description

  Manufacturer: Hafele
  Item: 940.94.002

  Product Title: Pocket Door Framing Kit, Futura, Type II

  Category: Pocket Door Framing Kit, Futura,

  Item Details …

  - Designed to fit into standard 2x4 wood or steel constructed interior walls

  - Provides an efficient way to save space in tight room designs

  - Specially engineered, cold-formed, zinc-plated steel studs prevent bowing of the pocket walls

  - Front steel studs have a special pocket to receive 1/2” thick sheetrock

  - Simple and straightforward installation

  - Wood header is produced out of plywood in order to prevent warping

  - Exposed part of wood header is laminated to match the color of the sliding track

  - Suitable for sliding doors installed into dining rooms, kitchens, bathrooms, closets or master bedrooms

  - For door thickness max. : 1 3/4”

  - For door height (inches) : 80” – 96”

  - Width (inch) : Door width: 24" – 48"

  - Area of application : For Junior 40Z and 80Z

  - Order reference

  - Supplied with: mounting instructions

  - Supplied with:

  - 1 x Header assembly

  - 2 x Front vertical stud

  - 2 x Back vertical stud

  - 4 x Floor plates (2 x front and 2 x back)

  - 2 x Filler strip

  - 1 x joing plate

  - Mounting screws


  Additional Information …

  Order Hawa Junior 40 Z or Hawa Junior 80 Z complete fitting set and the upper track separately.

• Data Sheet

  Detailed Data Sheet

• Product Resources

  TCH_Architectural_Hardware_2022|Page 1.227



• Specifications

  For detailed PDF specifications, click:
  Hafele Sliding Door Catalog Page: selection_1.189-1.191.pdf

  Hafele 940.94.002 Futura Framing Kit, type 2
