Hafele 940.94.004 Pocket Door Framing Kit, Futura Type IV

Product Information

• Description

  Hafele 940.94.004 Pocket Door Framing Kit, Futura
  Type IV

  Sliding hardware (fitting) set and door not included - we do not sell doors or panels.

  Application : For Junior 40Z and 80Z

  Suitable for : Jr. 80

  For door thickness : up to 44 mm (1 3/4��)



  Supplied with :

  • 1 x Header assembly
  • 2 x Front vertical stud
  • 2 x Back vertical stud
  • 4 x Floor plates (2 x front and 2 x back)
  • 2 x Filler strip
  • 1 x joing plate
  • Mounting screws





• Specifications

  For detailed PDF specifications, click:
  Hafele Sliding Door Catalog Page: selection_1.189-1.191.pdf

  Hafele 940.94.004 Futura Framing Kit, type 4


  • Hardware > Hardware Accessories
  • Hardware,Hafele,500-3000
  • Brand: Hafele
  • Part#: 940.94.004
  • Condition: new
