Hafele 262.36.520 RTA and Shelf Connector, Rasant-Tab for drill hole 3 or 5 mm, For wood thicknesses: from 19+ mm, nickel-plated

Product Information

• Description

  Manufacturer: Hafele
  Item: 262.36.520

  Product Title: RTA and Shelf Connector, Rasant-Tab, for drill hole Ø 5 mm, For wood thicknesses: from 19+ mm, nickel-plated

  Category: RTA and Shelf Connector, Rasant-Tab, for drill hole Ø 5 mm, For wood thicknesses: from 19+ mm, nickel-plated

  Item Details …

  - Same appearance and drilling pattern as Rafix 20 without pin.

  - The angled contact surfaces of the connector components allow shelves to be attached to the side panel with a positive-fitting connection.

  - Only the base plate of the support is visible after installation.

  - For wood thickness : ?19 mm

  - Drilling depth : 14.5 mm

  - Color/finish : Nickel plated, Nickel-plated

  - Installation : for screwing into drill hole Ø 3 or 5 mm

  - Area of application : Use M4 screw, sleeves for center panel application

  - Material : Support: Zinc alloyBoss insert: Plastic

  - Installation description : Support for screw fixing, boss insert for flush press-fitting into drill hole

  - Supplied with:

  - 1 support

  - 1 boss insert


  Additional Information …

  Use M4 screw, sleeves for center panel application
