Hafele 833.94.202 Profile 1104, Aluminum, Silver Finish with Opal Lens / 92 Inches

Product Information

• Description

  Manufacturer: Hafele
  Item: 833.94.202

  Product Title: Profile for recess mounting, Häfele Loox5 Profile 1104, for LED strip lights, Aluminum, Length: (92") 2336 mm, silver colored

  Category: Profile for recess mounting, Häfele Loox5 Profile 1104, for LED strip lights, Aluminum

  Item Details …

  - Light permeability : 60?–?70?%

  - Length : 2,336.00 mm

  - Length (inch) : 92"

  - Width (inch) : Diffuser: 5/16"

  - Material : Profile: Aluminum, Diffuser: Polycarbonate

  - Internal width : 8.00 mm

  - Diffuser width : 8.00 mm

  - Routing width : 10.90 mm

  - Routing depth : 12.00 mm

  - Installation : For recessing

  - Supplied with:

  - 1 profile

  - 1 diffuser


  Additional Information …

  For LED strip lights up to a width of max. 5 mm. Slide-in 7 mm wide clips from the side before installing the profile.The surface that is to be bonded must always be cleaned before bonding to the LED strip lights. It must be completely clean, grease-free and dust-free!DiffusersThe opal white diffuser creates a uniform light without points from 120 LEDs/ m. Points are visible with the black version. If required, please order alternative diffusers in black or transparent separately.

• Data Sheet

  Detailed Data Sheet

• Product Resources

  CAD data

  Loox – Electrical Code Compliance

  Hafele_Lighting_2024|Page 207
