Hafele 833.76.333 LED3044, 24 volts direct current 4.8 watts per meter 2700K-5000K CRI90 50 meters

Product Information

• Description

  Manufacturer: Hafele
  Item: 833.76.333

  Product Title: Flexible Strip Light, Häfele Loox5 LED 3044, 24 V, multi-white, (5/16") 8 mm, 2 x 120 LEDs/m, 4.8 W/m, Warm white 2700 K to cool white 5000 K, (1968 1/2") 50 m

  Category: Flexible Strip Light, Häfele Loox5 LED 3044, 24 V, multi-white, (5/16") 8 mm, 2 x 120 LEDs/m, 4.8 W/m

  Item Details …

  -

  - Optimized light mixture

  -

  - Cool white and warm white LEDs in the smallest of spaces

  - Optimal light mixture without flickering

  - Color temperature : 2700?–?5,000 K

  - Light color : Warm white to cool white

  - Nominal voltage : 24.00 V

  - Wattage/m : 4.80 W

  - Luminous flux/m : 425?–?465 lm

  - Luminous efficacy : 89?–?97 lm/W

  - Max. strip length (visual) : 8.50 m

  - Energy efficiency class : F

  - Height (inch) : 1/16"

  - Width (inch) : 5/16"

  - Dimmable : yes

  - Area of application : Plinths, behind furniture and objects, Ceiling light direct/indirect

  - Material : Plastic

  - Color : White

  - Strip width : 8.00 mm

  - Section length : 50.00 mm

  - Life time : L80/B10: >50,000 h

  - Color rendering index Ra : >90

  - Color rendering index R9 : >50

  - Degree of protection : IP20

  - Installation : Self-adhesive

  - Order reference

  - Please order lead separately. Color control via Häfele Connect Mesh 6-way distributor with multi-white adapter and remote control or smartphone. Please order separately. Installation of the free Häfele Connect Mesh app is required.

  - Supplied with:

  - 1 roll


  Additional Information …

  Maximum strip length (visual) describes a strip section with a visually imperceptible drop in luminous flux of max. 30%. Please note: A strip section with a new power supply that follows immediately is noticeably brighter.Max. wattage-dependent strip length on the driver, see technical data for LED strip lights.

• Data Sheet

  Detailed Data Sheet

• Product Resources

  CAD data

  Fitting instructions for Loox5 LED 2064 / 3070 / 3044 / 3047 / 3049

  Safety Notes for LED Strip Lights

  UL Certificate E473379 - US

  Loox – Electrical Code Compliance
