Hafele 406.02.081 Coplanar Door, EKU Frontino 20 H FS OL for Upper Cabinets, Complete Set For internal cabient width: (4' 7 1/8 - 5' 2 15/16") 1400 - 1599 mm

Product Information

• Description

  Hafele 406.02.081 Coplanar Door, EKU Frontino 20 H FS OL for Upper Cabinets, Complete Set
  For internal cabient width: (4' 7 1/8 - 5' 2 15/16") 1400 - 1599 mm



  Door weight : (44 lbs) 20 kg

  For door thickness : (3/4" - 1") 19 - 25 mm

  Door height : Max: (3' 3 3/8") 1000 mm
