Hafele 405.91.625 Sliding Door Hardware, EKU Combino 20 H Inslide, Set For Top Hung Wood Doors, for Door Heights up to 7' 2 5/8", For 2 Doors; Up to 44 lbs

Product Information

• Description

  Manufacturer: Hafele
  Item: 405.91.625

  Product Title: Sliding Door Hardware, Hawa Combino 20 IF, set, For Top Hung Wood Doors, for Door Heights up to 7' 2 5/8", For 2 Doors; Up to 44 lbs

  Category: Sliding Door Hardware, HAWA Combino 20/35 IF, set, For Top Hung Wood Doors, for Door Heights up to 7' 2 5/8"

  Item Details …

  - Tool-less door mounting via spring guide bolt

  - Elegant clip-on aluminum fascia

  - Recommended door overlay: 30 mm (1 3/16”)

  - Tool-less door mounting via spring guide bolt

  - Elegant clip-on aluminum fascia

  - Soft closing mechanism : with clip-in door stopper

  - For door thickness : 19 mm

  - For door width : ?1,200 mm

  - Set : Set without tracks

  - Area of application : For 2 doors

  - For door height : ?2,200 mm

  - Door stopper : Top clip-in door stopper, for sliding into double or single running track

  - Material/finish : Running gear: SteelGuide: PlasticRollers: PlasticAxis: Steel

  - Running position : Top

  - Running gear guided by : Ball bearing

  - Adjustment facility : Height adjustment: ±3 mm, ±3 mm on running gear using eccentric screw

  - Door adjustment via : eccentric screw

  - Installation : Guide for press fitting into a drill hole, Running gear for screw fixing, Backlash-free spring-loaded floor guide for press fixing

  - Running position : Top

  - Type of opening : linear

  - Number of doors per system max. : 2 to 3

  - Order reference

  - Please order running and guide track separately.

  - Supplied with:

  - Set Components Include:

  - Running gear

  - Mounting bracket

  - Track stopper with retainer

  - Track stopper

  - Guide

  - Buffer (2 different types)

  - Mounting screws

• Data Sheet

  Detailed Data Sheet

• Product Resources

  CAD data

  COMBINO 20 H IF Mounting Instructions

  TCH_Furniture_Cabinetry_Hardware_2022|Page 7.37



• Specifications

  Hafele 405.91.625, 405-91-625, 40591625, 405.91


  Specifications/Hafele Catalog - Page# FC7.37: Click to: Show catalog here ... Click to: Show catalog in a new page. Return to: Hafele Sliding & Roller Shutters Catalog Return to: All Hafele Catalogs

  Download Adobe PDF Reader





• Brand PDF Catalogs

  Click on a Category to open a PDF catalog:

  Sliding and Folding Catalog

  Fineline Brochure

  Free Flap Fittings Brochure

  The Complete Architectural Hardware Catalog

  Dialock In Hotels Catalog

  Dialock System Catalog

  IXConnect Invisible Heroes

  One Room One Face Catalog

  Architectural Hardware: American Standard Catalog

  Closet Catalog

  Decorative Wood Catalog

  Cornerstone Catalog

  Decorative Hardware Catalog

  Kitchen Solutions Catalog

  Loox5 Lighting Catalog

  Furniture Cabinetry Hardware Catalog

  Designing Accessibility HEWI Catalog

  The Complete Cabinet



• Required Products & Optional Accessories

  Note: Add the current product in cart before ordering required products below ...

  Required Products:

  Single Running Track, Hawa Combino 20 and 35 H IF (choose one):


  • for Hawa Combino IF/MF, Length: 8' 2 7/16" for Hawa Combino IF/MF, Length: 11' 5 13/16"

    406.30.967 406.30.976

    Click to order Click to order



  Double Running Track, Multihole (choose one):


  • for Hawa Combino IF/MF, Length: 8' 2 7/16" for Hawa Combino IF/MF, Length: 11' 5 13/16"

    406.31.964 406.31.973

    Click to order Click to order



  Bottom Guide Rail, for Hawa Combino/Clipo IF (choose one):


  • for Hawa Combino/Clipo IF, 2.5 m

    405.04.351

    Click to order



  Lower Guide Rail Channel, for Hawa Clipo 36 H IF (choose one):


  • 2.5 m 3.5 m

    406.73.803 406.73.804

    Click to order Click to order



  Optional Accessories:



  • Clip-on Fascia, For Hawa Combino 20/35 H IF
  • Clip-on Adapter for Wood Fascia, For screw fixing to panel and clip fixing to running track
  • Center Door Stopper, Hawa Combino 20 and 35 H Inslide
  • Soft and self closing mechanism, For Hawa Combino 20/35 VF/MF/IF
