Hafele 231.53.861 Safe-O-Mat - Coin Collect, 800 Series 2x quarters, right hand

Product Information

• Description

  Hafele 231.53.861 Safe-O-Mat® - Coin Collect, 800 Series
  2x quarters, right hand

  Additional items required to complete installation:
  Safe-O-Mat® Coin Return / Retain Lock,


  Mounting : Right

  Model series : 800 - Coin Collect

  Application : €˘ Fitness centers
  €˘ Amusement parks
  €˘ Resorts
  €˘ Transportation terminals

  Suitable for : Wood, laminate and plastic lockers

  Temperature resistance : (32şF - 140şF) 0 - 60 °C

  Material : Plastic
  Cash box: Steel

  Color : Gray

  Note :

  Please contact Hafele at 1-800-423-3531 and have the following information available:

  €śHanding€ť specifications

  Key Plan specifications

  Each lock requires (sold separately):

  Cylinder core and user key

  Cash box

  Every order requires (sold separately):

  Cylinder change (removal) key

  Master key

  Cash box key

  • Screw length depends on door thickness.
  • Other currency or token locks available upon request.



  Technical data :

  Technical Data

  Size (L x H x W)	111 mm x 119 x 57.5 mm
  	(4 5/16€ť x 6 7/8€ť x 2 1/4€ť)
  Weight	600 g (21 oz.)
  Temperature	0°C to 60°C (32°F to 140°F)
  Humidity	10% - 95% (non-condensing)
  Currency	1 quarter, 2 quarters , US, token
  Cash box capacity	40 quarters





  Optional items:
  Zip-R Screw, Flat Countersunk Head, #2 Phillips, with Nibs
  Zip-R Screw, Flat Countersunk Head, #2 Phillips Drive
  Zip-R Screw, Flat Countersunk Head, #2 Square Drive, with Nibs
  Zip-R Screw, Flat Countersunk Head, #2 Square Drive
  Spax® Screw, Flat Countersunk Head with Uni-Drive, Zinc-Plated


• Specifications

  For detailed PDF specifications, click:
  Hafele Catalog Page: selection_10.66-10.66.pdf



  Hafele 231.53.861 Safe-O-Mat Series 800 Collect $.50 Rh (12X11X11 Cm)


  Product Specifications:
  Contact us for more information.
