Hafele 230.28.620 Inlaid Lock, Symo, Backset 20 mm For combination with Symo cylinder removable core, Mounting: Drawer version (key turn to the right)

Product Information

• Description

  Manufacturer: Hafele
  Item: 230.28.620

  Product Title: Inlaid Lock, Symo, Backset 20 mm, For combination with Symo cylinder removable core, Mounting: Drawer version (key turn to the right)

  Category: Inlaid Lock, Symo, Backset 20 mm, For combination with Symo cylinder removable core, Mounting: Drawer version (key turn to the right)

  Item Details …

  - Mounting : Drawer version (key turn to the right)

  - Backset D : 25/32"

  - Area of application : For cylinder cores that are inserted from the front on-site

  - Version : Drawer

  - Material : Zinc alloy

  - Color/finish : Nickel plated

  - Backset (mm) : 20.00 mm

  - Cylinder shape : prepared for round cylinder

  - Cylinder length : 22.00 mm

  - Cylinder Diameter: (mm) : 18.00 mm

  - Installation : Screw-mount

  - with key : No
