Hafele 229.80.610 Lock Handle, Symo, Length 30 mm (1 3/16") For combination with Symo cylinder removable core, Right hand
Product Information
Description
Manufacturer: Hafele
Item: 229.80.610
Product Title: Lock Handle, Symo, Length 30 mm (1 3/16"), For combination with Symo cylinder removable core, Right hand
Category: Lock Handle, Symo, Length 30 mm (1 3/16"), For combination with Symo cylinder removable core
Item Details …
- Version : Without ringsWith insert for Symo cylinder cores (locking with key) or cover caps (locking without key)
- Finish : Matt
- Refinement : Nickel plated
- Color/finish : Nickel plated, Matt
- For door thickness min. : 19 mm
- Area of application : For all Symo locks and cylinder cores
- Material : Zinc alloy
- For door thickness : 19 mm
- Length : 30.00 mm
- Installation : Right
- Installation reference : For inserting into Symo locks.The rotary handle can be used with plate cylinder and pin tumbler cylinder removable cores (locking with or without key) and with cover caps (locking without key).Data Sheet
Product Resources
Specifications
Hafele 229.80.610 Rotary Knob Symo Zn Nip Matt 30X30Mm (5.3X3X2.5 Cm)
Product Specifications:
Contact us for more information.Brand PDF Catalogs
Click on a Category to open a PDF catalog:
Sliding and Folding Catalog
Fineline Brochure
Free Flap Fittings Brochure
The Complete Architectural Hardware Catalog
Dialock In Hotels Catalog
Dialock System Catalog
IXConnect Invisible Heroes
One Room One Face Catalog
Architectural Hardware: American Standard Catalog
Closet Catalog
Decorative Wood Catalog
Cornerstone Catalog
Decorative Hardware Catalog
Kitchen Solutions Catalog
Loox5 Lighting Catalog
Furniture Cabinetry Hardware Catalog
Designing Accessibility HEWI Catalog
The Complete CabinetRequired Products & Optional Accessories
Optional Accessories:- Plate-Cylinder Removable Core, Keyed Alike, Symo 3000
Quick Metric Conversions: 25mm = 1 inch (approx), 2.5cm = 1 inch (approx), 96mm = 3.75 inches
