Hafele 940.94.103 Pocket Door Framing Kit With Jr. Sliding Hardware Type III

Product Information

• Description

  Hafele 940.94.103 Pocket Door Framing Kit With Jr. Sliding Hardware
  Type III

  Doors not included - we do not sell doors or panels.

  Suitable for : door weights of up to either: 40 kg or 80 kg (88 lbs. or 176 lbs.)

  Width : Door panel: (39 3/4") 100 mm

  For door thickness : up to 44 mm (1 3/4��)

  Length : Track: (6' 6 3/4") 2000 mm



  Supplied with :

  • 1 x Header assembly
  • 2 x Front vertical stud
  • 2 x Back vertical stud
  • 4 x Floor plates (2 x front and 2 x back)
  • 2 x Filler strip
  • 1 x joing plate
  • Mounting screws





• Specifications

  For detailed PDF specifications, click:
  Hafele Sliding Door Catalog Page: selection_1.189-1.191.pdf

  Hafele 940.94.103 Futura Framing Kit Type III with HAWA Junior 80/Z se


  • Hardware > Hardware Accessories
  • Hardware,Hafele,500-3000
  • Brand: Hafele
  • Part#: 940.94.103
  • Condition: new
