Hafele 833.03.011 WarmTech Dim-to-Warm Hardwired Wall Switch Drivers

Product Information

• Description

  Manufacturer: Hafele
  Item: 833.03.011

  Product Title: Wall Switch with Dim-to-Warm Control, For Dim-to-Warm Control of Multi-White LED Lights, White

  Category: Wall Switch with Dim-to-Warm Control, For Dim-to-Warm Control of Multi-White LED Lights, White

  Item Details …

  - While dimming, color temperature simultaneously is reduced, simulating incandescent lights

  - Simple installation with no compatibility issues

  - Flicker-free dimming - Compliant to IEEE and Title 24

  - A single wall switch can control multiple drivers

  - Classic design to match existing style switches

  - Wattage : 600 W

  - Color/finish : White

  - Length : 119.00 mm

  - Length (inch) : 4 11/16"

  - Height (inch) : 1 3/4"

  - Width (inch) : 3 7/8"

  - Area of application : For on/off, and dim-to-warm control of 3-wire multi-white (tunable) lights

  - Material : Plastic

  - Dim. (L x W x H) : 119 x 75 x 41 mm

  - Installation reference : Fits US Standard gang box

  - Order reference

  - Use in conjunction with DimTone dimmable drivers (sold separately).

  - Supplied with:

  - Wall plate

  - Mounting screws

  - Wire nuts

  - Installation instructions

• Data Sheet

  Detailed Data Sheet

• Product Resources

  CL Dimmer Mounting Installation

  Loox – Electrical Code Compliance

  Hafele_Lighting_2024|Page 188

  Hafele_Lighting_2024|Page 298

  Hafele_Lighting_2024|Page 96



• Brand PDF Catalogs

  Click on a Category to open a PDF catalog:

  Sliding and Folding Catalog

  Fineline Brochure

  Free Flap Fittings Brochure

  The Complete Architectural Hardware Catalog

  Dialock In Hotels Catalog

  Dialock System Catalog

  IXConnect Invisible Heroes

  One Room One Face Catalog

  Architectural Hardware: American Standard Catalog

  Closet Catalog

  Decorative Wood Catalog

  Cornerstone Catalog

  Decorative Hardware Catalog

  Kitchen Solutions Catalog

  Loox5 Lighting Catalog

  Furniture Cabinetry Hardware Catalog

  Designing Accessibility HEWI Catalog

  The Complete Cabinet



• Required Products & Optional Accessories

  Note: Add the current product in cart before ordering required products below ...

  Required Products:

  DimTone Dimmable Driver, with Color Temperature Control (choose one):


  • 60W / 12 V 90W / 24 V

    833.03.005 833.03.007

    Click to order Click to order
