Hafele 774.24.243 186 and 187 Series Bracket, KV, for 86 & 187 Series Standards KV - weight capacity up to 1060 lbs./pair, Length 10", model 186LL ANO 10

Product Information

• Description

  Hafele 774.24.243 186 and 187 Series Bracket, KV, for 86 & 187 Series Standards
  KV - weight capacity up to 1060 lbs./pair, Length 10", model 186LL ANO 10



  Features : Super duty
  Double-lug brackets provide strong, secure weight-bearing support and help prevent shelves and contents from falling if bumped

  Adjustment : Adjustable in 2" increments

  Load bearing capacity : *Pair: Up to (1060 lbs.) 480 kg

  Model series : 186

  Gauge : 12

  Material : Steel

  Finish : Anochrome



  Supplied with :

  187 brackets include 3 lugs for additional support



  Optional items:
  Zip-R Screw, Flat Countersunk Head, #2 Phillips, with Nibs
  Zip-R Screw, Flat Countersunk Head, #2 Phillips Drive
  Zip-R Screw, Flat Countersunk Head, #2 Square Drive, with Nibs
  Zip-R Screw, Flat Countersunk Head, #2 Square Drive
  Zip-R Screw, Flat Countersunk Head with Uni-Drive, Zinc-Plated
  87 Series Standards, KV, 7/8" x 11/16", 12 ga. Steel


• Specifications

  For detailed PDF specifications, click:
  Hafele Catalog Page: selection_4.29-4.34.pdf

  Hafele 774.24.243, 774-24-243, 77424243, 774.24


  Specifications/Hafele Catalog - Page# FC11.63: Click to: Show catalog here ... Click to: Show catalog in a new page. Return to: Hafele Connectors & Shelf Supports Catalog Return to: All Hafele Catalogs
