Hafele 774.20.226 80 Series Standards, KV, 5/8" x 13/32", 16 ga. Steel weight capacity up to 320 lbs. / pair, Length 60", model 80 ANO 60

Product Information

• Description

  Manufacturer: Hafele
  Item: 774.20.226

  Product Title: 80 Series Standards, KV, 5/8" x 13/32", 16 ga. Steel, weight capacity up to 320 lbs. / pair, Length 60", model 80 ANO 60

  Category: 80 Series Standards, KV, 5/8" x 13/32", 16 ga. Steel, weight capacity up to 320 lbs. / pair

  Item Details …

  - Proper installation and mounting required. Tested to meet or exceed ANSI/BHMA 156.9-2003 performance standards. Weight limits are based on standards mounted on 16" centers and are intended for use as general guidelines only. No warranty, expressed or implied, supplied by Häfele.

  - Heavy duty

  - RoHS compliant

  - Made in USA

  - Adjustable in 1" increments

  - Gauge formula : 16.00

  - Color : White

  - Load bearing capacity : Pair: Up to 320 lbs

  - Model series : 80

  - Suitable for : Regular duty

  - Version : Double slot design

  - Unique selling points (USP) : Heavy dutyRoHS compliantMade in USAAdjustable in 1" increments

  - Special notes on usage : Proper installation and mounting required. Tested to meet or exceed ANSI/BHMA 156.9-2003 performance standards. Weight limits are based on standards mounted on 16" centers and are intended for use as general guidelines only. No warranty, expressed or implied, supplied by Häfele.

  - Adherence to standards : RoHS compliant

  - Width : 16.00 mm

  - Width (inch) : 5/8"

  - Depth : 18.00 mm

  - Depth (inch) : 13/32"

  - Material : Steel

  - Note : Screws are not included.

  - Load bearing capacity max. : 145.15 kg

  - Note on load bearing capacity : Based on per pair


  Additional Information …

  Screws are not included.
