Hafele 637.45.294 Adjustable Table Double Column, side mounted, steel, silver

Product Information

• Description

  Manufacturer: Hafele
  Item: 637.45.294

  Product Title: Adjustable Side Mounted Double Column Table System, STAR, silver

  Category: Adjustable Side Mounted Double Column Table System, STAR,

  Item Details …

  - With an integrated Collision Protection System for safety:

  - 1). AMP Draw – If the control box detects that any of the legs receive a spike in amp-draw due to, for example, something hitting the table, the table will reverse direction to avoid damage.

  - 2). Gyro Sensor – This internal sensor will detect the following:

  - • Sudden change in speed (up or down)

  - • Sudden change in the desk angle (up or down)

  - • An impact to the worksurface (up or down)

  - Stroke: 26”

  - Meets BIFMA X5.5 standards

  - UL 962 Recognized

  - Has an adjustable width support beam for mounting flexibility

  - Made in USA

  - Version : With 3 stage adjustable columnsWith 4-setting programmable switchAdjustable support channel, width adjusts from (42 1/2"–71") 1080–1803 mm

  - Material : Steel

  - Travel : 40 mm per second

  - Installation : Between 2 side panels or hidden inside a “wood box”Comes with welded-on side brackets for screw or bolt mounting to the panels

  - Area of application : Recommended for: Top widths: 48" - 76"Top depths: 24" - 30"

  - Height adjustment : 20 7/8” – 46 7/8”, not including top thickness

  - Load bearing capacity : 280 lbs including top weight

  - Supplied with:

  - 2 adjustable columns with welded on mounting brackets

  - Top supports and adjustable support channel

  - Double port control box

  - Programmable switch

  - Wiring and assembly hardware


  Additional Information …

  Make sure column is securely fastened to the panels, through bolts are recommended.Weight rating is based on an evenly distributed load over the tabletop.

• Data Sheet

  Detailed Data Sheet

• Product Resources

  STAR Double Column Side Mounting Instructions

  Troubleshooting Guide for 1 to 2 Column STAR Bases

  TCH_Furniture_Cabinetry_Hardware_2022|Page 6.61
