Hafele 635.48.350 Mini Table Leg, 30 mm Black semi-gloss, 500 mm (19 3/4")

Product Information

• Description

  Manufacturer: Hafele
  Item: 635.48.350

  Product Title: Mini Table Leg, Ø30 mm, Black semi-gloss, 500 mm (19 3/4")

  Category: Mini Table Leg, Ø30 mm,

  Item Details …

  - Tube thickness: 1 mm (1/16")

  - Area of application : For light duty applications

  - Foot/leg version : M10 threaded plastic insert

  - Diameter : 60.00 mm

  - Diameter (inch) : 1 3/16”

  - Material : SteelInsert: Plastic

  - Load bearing capacity : Static load rating: 66 lbs

  - Supplied with:

  - 4 legs


  Additional Information …

  Heights listed are without levelers (please order separately)

• Data Sheet

  Detailed Data Sheet

• Product Resources

  TCH_Furniture_Cabinetry_Hardware_2022|Page 6.36



• Specifications

  For detailed PDF specifications, click:
  Hafele Catalog Page: selection_6.28-6.28.pdf

  Hafele 635.48.350, 635-48-350, 63548350, 635.48


  Specifications/Hafele Catalog - Page# FC6.46: Click to: Show catalog here ... Click to: Show catalog in a new page. Return to: Hafele Table, Legs, Casters Catalog Return to: All Hafele Catalogs

  Download Adobe PDF Reader





• Brand PDF Catalogs

  Click on a Category to open a PDF catalog:

  Sliding and Folding Catalog

  Fineline Brochure

  Free Flap Fittings Brochure

  The Complete Architectural Hardware Catalog

  Dialock In Hotels Catalog

  Dialock System Catalog

  IXConnect Invisible Heroes

  One Room One Face Catalog

  Architectural Hardware: American Standard Catalog

  Closet Catalog

  Decorative Wood Catalog

  Cornerstone Catalog

  Decorative Hardware Catalog

  Kitchen Solutions Catalog

  Loox5 Lighting Catalog

  Furniture Cabinetry Hardware Catalog

  Designing Accessibility HEWI Catalog

  The Complete Cabinet



• Required Products & Optional Accessories

  Optional Accessories:



  • Base Leveler, M10 x 31 mm
  • Base Leveler, M10, Fixed
