Hafele 552.26.524 MATRIX BOX SLIM A30 SFTC ANTH 89X450MM For 500mm drawer depth

Product Information

• Description

  Manufacturer: Hafele
  Item: 552.26.524

  Product Title: Drawer side runner system, Häfele Matrix Box Slim A, 89 mm Drawer Height, (17 11/16") 450 mm nominal length; anthracite

  Category: Drawer side runner system, Häfele Matrix Box Slim A, 89 mm Drawer Height,

  Item Details …

  - Load bearing capacity : 30.00 kg

  - Load bearing capacity : 66 lbs

  - Material : Runners: Steel

  - Drawer side height : 89.00 mm

  - Drawer side height : 3 1/2"

  - Adjustment facility : Front gap adjustment: 0-3 mmHeight adjustment: 0-3 mmSide adjustment: ± 1 mmTilt adjustment: 0-3 mm

• Data Sheet

  Detailed Data Sheet

• Product Resources

  Matrix Box Slim A H89 installation instructions

  Matrix Box Slim A30 H89 Mounting Instructions

  Certificate

  TCH_Furniture_Cabinetry_Hardware_2022|Page 8.19



• Brand PDF Catalogs

  Click on a Category to open a PDF catalog:

  Sliding and Folding Catalog

  Fineline Brochure

  Free Flap Fittings Brochure

  The Complete Architectural Hardware Catalog

  Dialock In Hotels Catalog

  Dialock System Catalog

  IXConnect Invisible Heroes

  One Room One Face Catalog

  Architectural Hardware: American Standard Catalog

  Closet Catalog

  Decorative Wood Catalog

  Cornerstone Catalog

  Decorative Hardware Catalog

  Kitchen Solutions Catalog

  Loox5 Lighting Catalog

  Furniture Cabinetry Hardware Catalog

  Designing Accessibility HEWI Catalog

  The Complete Cabinet



• Required Products & Optional Accessories

  Optional Accessories:



  • Front fixing bracket, Matrix Box Slim A
  • Front fixing bracket, Häfele Matrix Box Slim A
  • Inner Divider, For Matrix Box Slim A30
  • Cross railing holder, Häfele Matrix Box Slim A
  • Panel, For Matrix Box Slim A30
  • Front Bracket Set, Matrix Box Slim A30, 89 mm (3 1/2") Side Height
  • Side Railing, Häfele Matrix Box Slim A
