Hafele 433.29.004 Accuride C3135 Undermount Slide, Easy Close, Commerical Grade 16" extension, D-Pack

Product Information

• Description

  Manufacturer: Hafele
  Item: 433.29.004

  Product Title: Accuride C3135 Undermount Slide, Easy Close, Commerical Grade, 16" extension, D-Pack

  Category: Accuride C3135 Undermount Slide, Easy Close, Commerical Grade,

  Item Details …

  - Commercial grade

  - Easy close mechanism consistently brings drawers to a gentle close

  - Fluid damper resists slam without adding bounce back

  - Lower space clip reduces migration and side to side movement

  - Meets ADA requirements with 4.8 lbs of pull force (up to 100 lbs.)

  - For drawers up to 30� wide

  - Frameless or face frame with back bracket

  - Model series : 3135EC

  - Features : D pack

  - Comfort functions opening/closing : Soft close fluid damped

  - Load bearing capacity : 45.50 kg

  - Load bearing capacity : 100 lbs

  - Material : Steel

  - Color/finish : Bright electro zinc

  - Supplied with:

  - D-Pack includes: 1 pair per box, 6 x #8 x 5/8� screw, disconnect levers, 4 x #6 x 5/8� screws and installation instructions

• Data Sheet

  Detailed Data Sheet

• Product Resources

  TCH_Furniture_Cabinetry_Hardware_2022|Page 8.78



• Brand PDF Catalogs

  Click on a Category to open a PDF catalog:

  Sliding and Folding Catalog

  Fineline Brochure

  Free Flap Fittings Brochure

  The Complete Architectural Hardware Catalog

  Dialock In Hotels Catalog

  Dialock System Catalog

  IXConnect Invisible Heroes

  One Room One Face Catalog

  Architectural Hardware: American Standard Catalog

  Closet Catalog

  Decorative Wood Catalog

  Cornerstone Catalog

  Decorative Hardware Catalog

  Kitchen Solutions Catalog

  Loox5 Lighting Catalog

  Furniture Cabinetry Hardware Catalog

  Designing Accessibility HEWI Catalog

  The Complete Cabinet



• Required Products & Optional Accessories

  Optional Accessories:



  • Bottom Mount Bracket, for 3135EC, C3132EC and C3132SC
  • Rear Mount Face Frame Bracket, for 3135EC and 3132
  • Inset Face Frame Bracket, for 3135EC, C3132EC and C3132SC
  • Drill Jig, for C3132EC and C3132SC
