Hafele 433.17.845 Salice A7557 Futura Push Slide, for Face-Frame, Full Extension, 75 lbs 457 mm drawer box length

Product Information

• Description

  Manufacturer: Hafele
  Item: 433.17.845

  Product Title: Salice A7557 Futura Push Slide, for Face-Frame, Full Extension, 75 lbs, 457 mm drawer box length

  Category: Salice A7557 Futura Push Slide, for Face-Frame, Full Extension, 75 lbs,

  Item Details …

  - Slight pressure on the drawer front opens the drawer

  - “Push” mechanism is fully integrated into the slide

  - Slotted hole for depth adjustment

  - Front clip disconnect for easy drawer insertion and removal

  - Perfect for drawers without handles

  - Model : A7557 Futura

  - Version : Push-to-Open(must manually push to close)

  - Model series : A7557 Futura Push Face-Frame Mounted

  - Type of pull out : Full extension

  - Features : With self-closing mechanismwith soft-closing mechanism

  - Comfort functions opening/closing : Push to open

  - Load bearing capacity : 35.00 kg

  - Load bearing capacity : Per pair: 75 lbs

  - Adjustment facility : Height adjustment + 3 mm

  - Material : Steel

  - Color/finish : Zinc

  - Installation : For screw fixing to side panel into 32 mm series drilled holesfor screw fixing to drawer, with mounting clip

• Data Sheet

  Detailed Data Sheet

• Product Resources

  TCH_Furniture_Cabinetry_Hardware_2022|Page 8.60



• Specifications

  For detailed PDF specifications, click:
  Hafele Catalog Page: selection_8.29-8.31.pdf

  Hafele 433.17.845, 433-17-845, 43317845, 433.17


  Specifications/Hafele Catalog - Page# FC8.15: Click to: Show catalog here ... Click to: Show catalog in a new page. Return to: Hafele Drawer Slides Catalog Return to: All Hafele Catalogs

  Download Adobe PDF Reader





• Brand PDF Catalogs

  Click on a Category to open a PDF catalog:

  Sliding and Folding Catalog

  Fineline Brochure

  Free Flap Fittings Brochure

  The Complete Architectural Hardware Catalog

  Dialock In Hotels Catalog

  Dialock System Catalog

  IXConnect Invisible Heroes

  One Room One Face Catalog

  Architectural Hardware: American Standard Catalog

  Closet Catalog

  Decorative Wood Catalog

  Cornerstone Catalog

  Decorative Hardware Catalog

  Kitchen Solutions Catalog

  Loox5 Lighting Catalog

  Furniture Cabinetry Hardware Catalog

  Designing Accessibility HEWI Catalog

  The Complete Cabinet



• Required Products & Optional Accessories

  Note: Add the current product in cart before ordering required products below ...

  Required Products:

  Six-Way Adjustable Disconnect Clips, for Salice Futura Slides (choose one):


  • Orange, 6-way adjustable

    421.23.001

    Click to order



  Height Adjustable Disconnect Clips, for Salice Futura Slides (choose one):


  • Gray

    421.23.000

    Click to order



  Optional Accessories:



  • Mounting Bracket, for Face Frame Cabinets
