Hafele 409.36.036 Slido F-Fold61 25A, with standard hinge, without covercap, left and right hand, 25 kg

Product Information

• Description

  Manufacturer: Hafele
  Item: 409.36.036

  Product Title: Sliding door fitting, For Slido F-Fold 61 25A/50A Set, For wooden/aluminum folding sliding doors, With standard center hinge without cover cap, left and right as set, door weight 55 lbs.

  Category: Sliding door fitting, For Slido F-Fold 61 25A/50A Set, For wooden/aluminum folding sliding doors

  Item Details …

  - Ideal for laterally connected doors

  - Set : Set without tracks

  - Length (inch) : 2' 1 19/32"

  - Area of application : for wooden doors,for aluminium frame doors with frame width >50 mm

  - For door material : wood, aluminium frame

  - For door thickness : ?16 mm

  - Note on door weight : 12.5/25 kg (25/50 kg per pair of doors)

  - Note on door width : 25 kg: ?450 mm,50 kg: ?600 mm

  - Material/finish : Rollers: Plastic

  - Running gear version : 4 rollers

  - Running gear guided by : Ball bearing

  - Adjustment facility : Adjustable via hinges

  - Door adjustment via : Hinges

  - Installation : Left and right as set

  - Model series : F-Fold61

  - Order reference

  - The running tracks, the fixing material and the concealed hinges for lateral connection are not included in the set. Please order separately.

  - Supplied with:

  - 1 running gear with 1 concealed hinge for left door

  - 1 running gear with 1 concealed hinge for right door

  - 8 panel to panel hinges


  Additional Information …

  From door leaf weight ?25 kg, door leaf height ?2400 mm or door leaf width ?450 mm, the use of the guide rail below is recommended.
