Hafele 329.69.013 Clip Mounting Plate, Salice, with Pre-Installed 11 mm Euro Screws for screw fixing, quick fixing system, depth and height adjustment via eccentric, 3 mm, BARGL39F/16

Product Information

• Description

  Manufacturer: Hafele
  Item: 329.69.013

  Product Title: Clip Mounting Plate, Salice, with Pre-Installed 11 mm Euro Screws, quick fixing system, fixing with chipboard screws, depth adjustable via eccentric, 3 mm, BARGL39F/16

  Category: Clip Mounting Plate, Salice, with Pre-Installed 11 mm Euro Screws, quick fixing system, fixing with chipboard screws, depth adjustable via eccentric

  Item Details …

  - Area of application : For Häfele Metalla 510 concealed hinges

  - Material : Steel

  - Color/finish : nickel plated

  - For drill hole Ø : 5.00 mm

  - For side panel thickness : 19 mm

  - Drilling depth : 11.00 mm

  - Screw distance : 32.00 mm

  - Edge distance : 37.00 mm

  - Adjustment facility : Height adjustment Via eccentric, Depth adjustment Via eccentric

  - Fixing method : Quick fixing system SM

  - Mounting plate version : For screw fixing with pre-mounted Euro screws

  - Manufacturer : Häfele

  - Model series : Metalla 510 SM

• Data Sheet

  Detailed Data Sheet

• Product Resources

  CAD data

  TCH_Furniture_Cabinetry_Hardware_2022|Page 9.39



• Specifications

  For detailed PDF specifications, click:
  Hafele Catalog Page: selection_9.38-9.43.pdf

  Hafele 329.69.013, 329-69-013, 32969013, 329.69


  Specifications/Hafele Catalog - Page# FC9.42: Click to: Show catalog here ... Click to: Show catalog in a new page. Return to: Hafele Hinges & Stays Catalog Return to: All Hafele Catalogs
