Hafele 234.65.000 Push-Button Lock, for all Cores Timberline- modular removable core locking system

Product Information

• Description

  Manufacturer: Hafele
  Item: 234.65.000

  Product Title: Push-Button Lock, for all Cores, Timberline modular removable core locking system

  Category: Push-Button Lock, for all Cores, Timberline modular removable core locking system

  Item Details …

  - Lock sliding doors

  - Compatible with all cores

  - Small 3/4� diameter for improved appearance

  - Model : CB-175

  - Material : Lock case: NylonCylinder housing: Die-cast zinc

  - Bolt throw : 8.00 mm

  - Bolt throw : 5/16"

• Data Sheet

  Detailed Data Sheet

• Product Resources

  TCH_Furniture_Cabinetry_Hardware_2022|Page 10.11



• Specifications

  For detailed PDF specifications, click:
  Hafele Catalog Page: selection_10.10-10.11.pdf

  Hafele 234.65.000, 234-65-000, 23465000, 234.65


  Specifications/Hafele Catalog - Page# FC10.13: Click to: Show catalog here ... Click to: Show catalog in a new page. Return to: Hafele Lockers & Locking Systems Catalog Return to: All Hafele Catalogs
