Hafele 433.29.021 Accuride C3135 Undermount Slide, Easy Close, Commerical Grade 12" extension, P-Pack

Product Information

• Description

  Hafele 433.29.021 Accuride C3135 Undermount Slide, Easy Close, Commerical Grade
  12" extension, P-Pack

  Note: This product can only be purchased in minimum quantity of 6

  Additional items required to complete installation:
  Horizontal Disconnect Lever, for Accuride 3135EC


  Finish : Bright electro zinc

  Model series : 3135EC

  Closing effect : Easy Close

  Load bearing capacity : (100 lbs) 45.5 kg

  Adjustment : 1/8" vertical, horizontal & depth adjustment

  Application : Frameless or FaceFrame with back bracket

  Material : Steel

  Finish : Bright electro zinc



  Supplied with :

  D-Pack includes: 1 pair per box, 6 x #8 x 5/8�� screw, disconnect levers, 4 x #6 x 5/8�� screws and installation instructions

  P-Pack includes: 6 x 12-24�� slides per box or 4 x 26-28�� slides per box (disconnect levers & screws sold seperately)



  Optional items:
  Rear Mount Face Frame Bracket, for 3135EC and 3132
  Bottom Mount Bracket, for 3135EC, C3132EC and C3132SC
  Inset Face Frame Bracket, for 3135EC, C3132EC and C3132SC
